Zenith dependence of neutrino fluxes

This notebook demonstrates how to compute the zenith distribution for neutrinos at fixed energy.

#basic imports and jupyter setup
#import primary model choices
import crflux.models as pm
import matplotlib.pyplot as plt
import numpy as np

#import solver related modules
from MCEq.core import MCEqRun

In the present case, we choose the MSIS00_IC density model. The origin of the coordinate system is centered at the South Pole. The zenith angle can vary between \(0^\circ\) (vertical) and \(180^\circ\) (vertical up-going from North Pole).

mceq_run = MCEqRun(
#provide the string of the interaction model
interaction_model='SIBYLL2.3c',
#primary cosmic ray flux model
#support a tuple (primary model class (not instance!), arguments)
primary_model = (pm.HillasGaisser2012, "H3a"),
# Zenith angle in degrees. 0=vertical, 90=horizontal
theta_deg=0.0,
#density model
density_model=('MSIS00_IC',('SouthPole','January')),
)

MCEqRun::set_interaction_model(): SIBYLL23C
ParticleManager::_init_default_tracking(): Initializing default tracking categories (pi, K, mu)
MCEqRun::set_density_model(): Setting density profile to MSIS00_IC ('SouthPole', 'January')
MSIS00IceCubeCentered::set_theta(): latitude = -90.00 for zenith angle =  0.00
MCEqRun::set_primary_model(): HillasGaisser2012 H3a

Define variables and angles

#Power of energy to scale the flux
mag = 3

#obtain energy grid (fixed) of the solution for the x-axis of the plots
e_grid = mceq_run.e_grid

#Dictionary for results
flux = {}

#Define equidistant grid in cos(theta)

cos_theta = np.linspace(-1,1,37)
angles = np.arccos(cos_theta)/np.pi*180.

Compute spectrum for each zenith angle and two seasons

For each zenith angle compute the whole spectrum. When plotting pick just one energy bin to plot the zenith distribution for leptons of fixed energy.

flux_summer = {}
flux_winter = {}

for flux, atm_tup in [(flux_summer,('MSIS00_IC', ('SouthPole', 'January'))),
                      (flux_winter,('MSIS00_IC', ('SouthPole', 'July')))]:
    mceq_run.set_density_model(atm_tup)
    #Initialize empty grid
    for frac in ['mu_conv','mu_pr','mu_total','mu_pi','mu_k',
                 'numu_conv','numu_pr','numu_total','numu_pi','numu_k',
                 'nue_conv','nue_pr','nue_total', 'nue_pi','nue_k',
                 'nutau_pr']:
        flux[frac] = []


    #Sum fluxes, calculated for different angles
    for theta in angles:
        mceq_run.set_theta_deg(theta)
        mceq_run.solve()
        #_conv means conventional (mostly pions and kaons)
        flux['mu_conv'].append(mceq_run.get_solution('conv_mu+', mag)
                           + mceq_run.get_solution('conv_mu-', mag))

        # _pr means prompt (the mother of the muon had a critical energy
        # higher than a D meson. Includes all charm and direct resonance
        # contribution)
        flux['mu_pr'].append(mceq_run.get_solution('pr_mu+', mag)
                         + mceq_run.get_solution('pr_mu-', mag))

        # total means conventional + prompt
        flux['mu_total'].append(mceq_run.get_solution('total_mu+', mag)
                            + mceq_run.get_solution('total_mu-', mag))
        # originating from pion or kaon decays
        flux['mu_pi'].append(mceq_run.get_solution('pi_mu+', mag)
                            + mceq_run.get_solution('pi_mu-', mag))
        flux['mu_k'].append(mceq_run.get_solution('k_mu+', mag)
                            + mceq_run.get_solution('k_mu-', mag))

        # same meaning of prefixes for muon neutrinos as for muons
        flux['numu_conv'].append(mceq_run.get_solution('conv_numu', mag)
                             + mceq_run.get_solution('conv_antinumu', mag))
        flux['numu_pr'].append(mceq_run.get_solution('pr_numu', mag)
                           + mceq_run.get_solution('pr_antinumu', mag))
        flux['numu_total'].append(mceq_run.get_solution('total_numu', mag)
                              + mceq_run.get_solution('total_antinumu', mag))
        flux['numu_pi'].append(mceq_run.get_solution('pi_numu', mag)
                              + mceq_run.get_solution('pi_antinumu', mag))
        flux['numu_k'].append(mceq_run.get_solution('k_numu', mag)
                              + mceq_run.get_solution('k_antinumu', mag))

        # same meaning of prefixes for electron neutrinos as for muons
        flux['nue_conv'].append(mceq_run.get_solution('conv_nue', mag)
                            + mceq_run.get_solution('conv_antinue', mag))

        flux['nue_pr'].append(mceq_run.get_solution('pr_nue', mag)
                          + mceq_run.get_solution('pr_antinue', mag))

        flux['nue_total'].append(mceq_run.get_solution('total_nue', mag)
                             + mceq_run.get_solution('total_antinue', mag))
        flux['nue_pi'].append(mceq_run.get_solution('pi_nue', mag)
                              + mceq_run.get_solution('pi_antinue', mag))
        flux['nue_k'].append(mceq_run.get_solution('k_nue', mag)
                              + mceq_run.get_solution('k_antinue', mag))

        # since there are no conventional tau neutrinos, prompt=total
        flux['nutau_pr'].append(mceq_run.get_solution('total_nutau', mag)
                            + mceq_run.get_solution('total_antinutau', mag))

MCEqRun::set_density_model(): Setting density profile to MSIS00_IC ('SouthPole', 'January')
MSIS00IceCubeCentered::set_theta(): latitude = -90.00 for zenith angle =  0.00
MSIS00IceCubeCentered::set_theta(): latitude = 90.00 for zenith angle = 180.00
MSIS00IceCubeCentered::set_theta(): theta = 180.00 below horizon. using theta =  0.00
MSIS00IceCubeCentered::set_theta(): latitude = 51.63 for zenith angle = 160.81
MSIS00IceCubeCentered::set_theta(): theta = 160.81 below horizon. using theta = 19.19
MSIS00IceCubeCentered::set_theta(): latitude = 35.48 for zenith angle = 152.73
MSIS00IceCubeCentered::set_theta(): theta = 152.73 below horizon. using theta = 27.27
MSIS00IceCubeCentered::set_theta(): latitude = 22.90 for zenith angle = 146.44
MSIS00IceCubeCentered::set_theta(): theta = 146.44 below horizon. using theta = 33.56
MSIS00IceCubeCentered::set_theta(): latitude = 12.13 for zenith angle = 141.06
MSIS00IceCubeCentered::set_theta(): theta = 141.06 below horizon. using theta = 38.94
MSIS00IceCubeCentered::set_theta(): latitude =  2.49 for zenith angle = 136.24
MSIS00IceCubeCentered::set_theta(): theta = 136.24 below horizon. using theta = 43.76
MSIS00IceCubeCentered::set_theta(): latitude = -6.36 for zenith angle = 131.81
MSIS00IceCubeCentered::set_theta(): theta = 131.81 below horizon. using theta = 48.19
MSIS00IceCubeCentered::set_theta(): latitude = -14.64 for zenith angle = 127.67
MSIS00IceCubeCentered::set_theta(): theta = 127.67 below horizon. using theta = 52.33
MSIS00IceCubeCentered::set_theta(): latitude = -22.48 for zenith angle = 123.75
MSIS00IceCubeCentered::set_theta(): theta = 123.75 below horizon. using theta = 56.25
MSIS00IceCubeCentered::set_theta(): latitude = -29.97 for zenith angle = 120.00
MSIS00IceCubeCentered::set_theta(): theta = 120.00 below horizon. using theta = 60.00
MSIS00IceCubeCentered::set_theta(): latitude = -37.19 for zenith angle = 116.39
MSIS00IceCubeCentered::set_theta(): theta = 116.39 below horizon. using theta = 63.61
MSIS00IceCubeCentered::set_theta(): latitude = -44.19 for zenith angle = 112.89
MSIS00IceCubeCentered::set_theta(): theta = 112.89 below horizon. using theta = 67.11
MSIS00IceCubeCentered::set_theta(): latitude = -51.01 for zenith angle = 109.47
MSIS00IceCubeCentered::set_theta(): theta = 109.47 below horizon. using theta = 70.53
MSIS00IceCubeCentered::set_theta(): latitude = -57.68 for zenith angle = 106.13
MSIS00IceCubeCentered::set_theta(): theta = 106.13 below horizon. using theta = 73.87
MSIS00IceCubeCentered::set_theta(): latitude = -64.24 for zenith angle = 102.84
MSIS00IceCubeCentered::set_theta(): theta = 102.84 below horizon. using theta = 77.16
MSIS00IceCubeCentered::set_theta(): latitude = -70.71 for zenith angle = 99.59
MSIS00IceCubeCentered::set_theta(): theta = 99.59 below horizon. using theta = 80.41
MSIS00IceCubeCentered::set_theta(): latitude = -77.09 for zenith angle = 96.38
MSIS00IceCubeCentered::set_theta(): theta = 96.38 below horizon. using theta = 83.62
MSIS00IceCubeCentered::set_theta(): latitude = -83.33 for zenith angle = 93.18
MSIS00IceCubeCentered::set_theta(): theta = 93.18 below horizon. using theta = 86.82
MSIS00IceCubeCentered::set_theta(): latitude = -88.59 for zenith angle = 90.00
MSIS00IceCubeCentered::set_theta(): latitude = -89.70 for zenith angle = 86.82
MSIS00IceCubeCentered::set_theta(): latitude = -89.85 for zenith angle = 83.62
MSIS00IceCubeCentered::set_theta(): latitude = -89.90 for zenith angle = 80.41
MSIS00IceCubeCentered::set_theta(): latitude = -89.92 for zenith angle = 77.16
MSIS00IceCubeCentered::set_theta(): latitude = -89.94 for zenith angle = 73.87
MSIS00IceCubeCentered::set_theta(): latitude = -89.95 for zenith angle = 70.53
MSIS00IceCubeCentered::set_theta(): latitude = -89.96 for zenith angle = 67.11
MSIS00IceCubeCentered::set_theta(): latitude = -89.96 for zenith angle = 63.61
MSIS00IceCubeCentered::set_theta(): latitude = -89.97 for zenith angle = 60.00
MSIS00IceCubeCentered::set_theta(): latitude = -89.97 for zenith angle = 56.25
MSIS00IceCubeCentered::set_theta(): latitude = -89.98 for zenith angle = 52.33
MSIS00IceCubeCentered::set_theta(): latitude = -89.98 for zenith angle = 48.19
MSIS00IceCubeCentered::set_theta(): latitude = -89.98 for zenith angle = 43.76
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 38.94
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 33.56
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 27.27
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 19.19
MSIS00IceCubeCentered::set_theta(): latitude = -90.00 for zenith angle =  0.00
MCEqRun::set_density_model(): Setting density profile to MSIS00_IC ('SouthPole', 'July')
MSIS00IceCubeCentered::set_theta(): latitude = -90.00 for zenith angle =  0.00
MSIS00IceCubeCentered::set_theta(): latitude = 90.00 for zenith angle = 180.00
MSIS00IceCubeCentered::set_theta(): theta = 180.00 below horizon. using theta =  0.00
MSIS00IceCubeCentered::set_theta(): latitude = 51.63 for zenith angle = 160.81
MSIS00IceCubeCentered::set_theta(): theta = 160.81 below horizon. using theta = 19.19
MSIS00IceCubeCentered::set_theta(): latitude = 35.48 for zenith angle = 152.73
MSIS00IceCubeCentered::set_theta(): theta = 152.73 below horizon. using theta = 27.27
MSIS00IceCubeCentered::set_theta(): latitude = 22.90 for zenith angle = 146.44
MSIS00IceCubeCentered::set_theta(): theta = 146.44 below horizon. using theta = 33.56
MSIS00IceCubeCentered::set_theta(): latitude = 12.13 for zenith angle = 141.06
MSIS00IceCubeCentered::set_theta(): theta = 141.06 below horizon. using theta = 38.94
MSIS00IceCubeCentered::set_theta(): latitude =  2.49 for zenith angle = 136.24
MSIS00IceCubeCentered::set_theta(): theta = 136.24 below horizon. using theta = 43.76
MSIS00IceCubeCentered::set_theta(): latitude = -6.36 for zenith angle = 131.81
MSIS00IceCubeCentered::set_theta(): theta = 131.81 below horizon. using theta = 48.19
MSIS00IceCubeCentered::set_theta(): latitude = -14.64 for zenith angle = 127.67
MSIS00IceCubeCentered::set_theta(): theta = 127.67 below horizon. using theta = 52.33
MSIS00IceCubeCentered::set_theta(): latitude = -22.48 for zenith angle = 123.75
MSIS00IceCubeCentered::set_theta(): theta = 123.75 below horizon. using theta = 56.25
MSIS00IceCubeCentered::set_theta(): latitude = -29.97 for zenith angle = 120.00
MSIS00IceCubeCentered::set_theta(): theta = 120.00 below horizon. using theta = 60.00
MSIS00IceCubeCentered::set_theta(): latitude = -37.19 for zenith angle = 116.39
MSIS00IceCubeCentered::set_theta(): theta = 116.39 below horizon. using theta = 63.61
MSIS00IceCubeCentered::set_theta(): latitude = -44.19 for zenith angle = 112.89
MSIS00IceCubeCentered::set_theta(): theta = 112.89 below horizon. using theta = 67.11
MSIS00IceCubeCentered::set_theta(): latitude = -51.01 for zenith angle = 109.47
MSIS00IceCubeCentered::set_theta(): theta = 109.47 below horizon. using theta = 70.53
MSIS00IceCubeCentered::set_theta(): latitude = -57.68 for zenith angle = 106.13
MSIS00IceCubeCentered::set_theta(): theta = 106.13 below horizon. using theta = 73.87
MSIS00IceCubeCentered::set_theta(): latitude = -64.24 for zenith angle = 102.84
MSIS00IceCubeCentered::set_theta(): theta = 102.84 below horizon. using theta = 77.16
MSIS00IceCubeCentered::set_theta(): latitude = -70.71 for zenith angle = 99.59
MSIS00IceCubeCentered::set_theta(): theta = 99.59 below horizon. using theta = 80.41
MSIS00IceCubeCentered::set_theta(): latitude = -77.09 for zenith angle = 96.38
MSIS00IceCubeCentered::set_theta(): theta = 96.38 below horizon. using theta = 83.62
MSIS00IceCubeCentered::set_theta(): latitude = -83.33 for zenith angle = 93.18
MSIS00IceCubeCentered::set_theta(): theta = 93.18 below horizon. using theta = 86.82
MSIS00IceCubeCentered::set_theta(): latitude = -88.59 for zenith angle = 90.00
MSIS00IceCubeCentered::set_theta(): latitude = -89.70 for zenith angle = 86.82
MSIS00IceCubeCentered::set_theta(): latitude = -89.85 for zenith angle = 83.62
MSIS00IceCubeCentered::set_theta(): latitude = -89.90 for zenith angle = 80.41
MSIS00IceCubeCentered::set_theta(): latitude = -89.92 for zenith angle = 77.16
MSIS00IceCubeCentered::set_theta(): latitude = -89.94 for zenith angle = 73.87
MSIS00IceCubeCentered::set_theta(): latitude = -89.95 for zenith angle = 70.53
MSIS00IceCubeCentered::set_theta(): latitude = -89.96 for zenith angle = 67.11
MSIS00IceCubeCentered::set_theta(): latitude = -89.96 for zenith angle = 63.61
MSIS00IceCubeCentered::set_theta(): latitude = -89.97 for zenith angle = 60.00
MSIS00IceCubeCentered::set_theta(): latitude = -89.97 for zenith angle = 56.25
MSIS00IceCubeCentered::set_theta(): latitude = -89.98 for zenith angle = 52.33
MSIS00IceCubeCentered::set_theta(): latitude = -89.98 for zenith angle = 48.19
MSIS00IceCubeCentered::set_theta(): latitude = -89.98 for zenith angle = 43.76
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 38.94
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 33.56
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 27.27
MSIS00IceCubeCentered::set_theta(): latitude = -89.99 for zenith angle = 19.19
MSIS00IceCubeCentered::set_theta(): latitude = -90.00 for zenith angle =  0.00

# Plot seasons?
seasons = True

Plot muon neutrinos from down- to up-going zenith (averaged over azimuth). Solid=summer, dashed=winter.

closest_MCEq_energy_idx = lambda e: np.argmin(np.abs(e-mceq_run.e_grid))

idx0 = closest_MCEq_energy_idx(10.) + 1# 10 GeV
idx1 = closest_MCEq_energy_idx(10e3) + 1# 10 TeV
idx2 = closest_MCEq_energy_idx(1e6) + 1 # 1 PeV

ylim = [2e-5, 4e-14, 6e-22]

fig, axes = plt.subplots(1,3,sharex=True,figsize=(9.8,3.))
for i, idx in enumerate([idx0, idx1, idx2]):
    ax = axes[i]
    ax.text(0.01,0.9,rf' $E(\nu_\mu)=${e_grid[idx]:2.1e} GeV',
           transform=ax.transAxes)
    for sid, flux in enumerate([flux_summer, flux_winter]):
        if not seasons and sid > 0: continue
        pi_numu = [fl[idx]/e_grid[idx]**mag for fl, fln
                     in zip(flux['numu_pi'],flux['numu_total'])]
        k_numu = [fl[idx]/e_grid[idx]**mag for fl, fln
                     in zip(flux['numu_k'],flux['numu_total'])]
        pr_numu = [fl[idx]/e_grid[idx]**mag for fl, fln
                     in zip(flux['numu_pr'],flux['numu_total'])]
        ax.plot(cos_theta,pi_numu,
                 label=(r'from $\pi$ decay' if (i==0 and sid==0) else '_nolabel_'),
                 ls='-' if sid==0 else '--',lw=1.5, color='b')
        ax.plot(cos_theta,k_numu,
                 label=('from $K$ decay' if (i==0 and sid==0) else '_nolabel_'),
                 ls='-' if sid==0 else '--',lw=1.5, color='g')
        ax.plot(cos_theta,pr_numu,label=('from prompt decays'
                 if (i==0 and sid==0) else '_nolabel_'),
                 ls='-' if sid==0 else '--',lw=1.5, color='r')

        ax.set_ylim(0,ylim[i])
        ax.set_xlabel(r'$\cos(\theta)$ (IceCube)')

axes[0].set_ylabel(r"$\Phi_{\nu_\mu}$ [cm$^{2}$ s sr GeV]$^{-1}$")

plt.figlegend(*axes[0].get_legend_handles_labels(), loc=(0.45,0.9), ncol=3, frameon=False)

plt.tight_layout(rect=[0.0,0.0,1.,.92], pad=0.05)

# Uncomment to save plot
# plt.savefig('zenith_distribution_numu.png', dpi=300)

Plot muons from down-going to horizontal zenith (averaged over azimuth)

ylim = [7e-5, 12e-14, 15e-22]

fig, axes = plt.subplots(1,3,sharex=True,figsize=(9.8,3.))
for i, idx in enumerate([idx0, idx1, idx2]):
    ax = axes[i]
    ax.text(0.01,0.9,rf' $E(\mu)=${e_grid[idx]:2.1e} GeV',
           transform=ax.transAxes)
    for sid, flux in enumerate([flux_summer, flux_winter]):
        if not seasons and sid > 0: continue

        pi_mu = [fl[idx]/e_grid[idx]**mag for fl, fln
                     in zip(flux['mu_pi'],flux['mu_total'])]
        k_mu = [fl[idx]/e_grid[idx]**mag for fl, fln
                     in zip(flux['mu_k'],flux['mu_total'])]
        pr_mu = [fl[idx]/e_grid[idx]**mag for fl, fln
                     in zip(flux['mu_pr'],flux['mu_total'])]
        ax.plot(cos_theta,pi_mu,
                 label=(r'from $\pi$ decay' if (i==0 and sid==0) else '_nolabel_'),
                 ls='-' if sid==0 else '--',lw=1.5, color='b')
        ax.plot(cos_theta,k_mu,
                 label=('from $K$ decay' if (i==0 and sid==0) else '_nolabel_'),
                 ls='-' if sid==0 else '--',lw=1.5, color='g')
        ax.plot(cos_theta,pr_mu,label=('from prompt decays'
                 if (i==0 and sid==0) else '_nolabel_'),
                 ls='-' if sid==0 else '--',lw=1.5, color='r')

        ax.set_ylim(0,ylim[i])
        ax.set_xlabel(r'$\cos(\theta)$ (IceCube)')

axes[0].set_ylabel(r"$\Phi_{\mu}$ [cm$^{2}$ s sr GeV]$^{-1}$")
axes[0].set_xlim(0, 1)
plt.figlegend(*axes[0].get_legend_handles_labels(), loc=(0.45,0.9), ncol=3, frameon=False)

plt.tight_layout(rect=[0.0,0.0,1.,.92], pad=0.05)

# Uncomment to save plot
# plt.savefig('zenith_distribution_muons.png', dpi=300)
